Cooling Chemicals Are Necessity At Cooling Towers:
In a cooling chemical water system with a cooling tower, cool water is pumped away from the cooling tower and is circulated through the heat exchangers thereby cooling another medium and the water from the cooling tower becomes warmer. The warmed water then returns back to the cooling tower. In a Cooling Tower Chemical, the warmed water is sprayed downward, and the air is blown upward with a fan. As the warmed water droplets contact the air, some of the water droplets evaporate, and the air absorbs the heat released from this evaporation, thereby lowering the temperature of the remaining water. Advanced chemical and engineering are serving you with the best since forever.
Cooling Tower Chemical – Treatment Program Objectives:
The prescribed treatment program will maximize plant efficiency and reliability by minimizing problems associated with corrosion and deposition. The treatment program is designed to accomplish the following objectives:
- Control and minimize Cooling Tower Chemical water system corrosion
- Control and minimize deposition and scale
- Control microbiological population
- To be able to operate at the highest cycles of concentration.
“THE OBJECTIVE OF THE COOLING TOWER WATER MANAGEMENT IS TO ELIMINATE THE PROBLEMS OF SCALING, CORROSION BY MANAGING THE MAKE-UP WATER AND COOLING TOWER WATER AS PER THE SPECIFIED NORMS”.
SA –500 (W S C P)
Liquid -Biocide Buck man Laboratories, Singapore
GENERAL DECRIPTION
SA – 500 is a liquid formulation of cationic polymer. This product is particularly effect in recirculation cooling water
systems. This polymeric quaternary compound retains its effect charge over a white pH range. This product control
algae, fungi, slime and bacteria.
A BOARD SPECTRUM MICRO BIOCIDE CONCENTRATE
SA – 500 is a polymeric cationic micro biocide concentrate that can be diluted with water to formulate micro biocide
of any desired lower concentration. Such micro biocide are effective in controlling the growth of algae, bacteria and
fungi in recirculation cooling water system and the growth of slime forming bacteria and fungi in heat exchangers.
They are also effective in controlling the growth of algae in swimming pools, holding ponds and reservoirs and the
growth of bacteria and fungi in holding and processing tanks of industrial fresh Water systems. SA – 500 micro
biocide can be used in both acidic and alkaline systems and, unlike conventional quats, SA – 500 does not cause
foam. It is non-volatile and therefore is not lost by evaporation.
TYPICAL CHARACTERISTICS
- 1. Density @ 250C (770F) ………………….... 1.14-1.18 g/ml
- 2. Approximate weight per U.S. gallon……… 9.7lb
- 3. Approximate volume per pound…………... 391 ml
- 4. Approximate volume per kilogram………... 862 ml
- 5. Flash point (PMCC)……………………….. 1000C (2120F)
- 6. PH (1000 ppm in water)…………………… 5.7
BENEFITS
SA – 500 is designed to:
- 1. Control both gram-positive and gram-negative bacteria.
- 2. Control algae fungal growths in cooling water systems
- 3. Provide bactetiostatic action at low concentrations.
- 4. Provide effect control in hard waters.
- 5. Provide grater activity in the presence of organic contamination.
SA – 700 (ANTISCALENT)
Liquid - (Sequestering-Dispersing, Anticorrosive Agent) Ecolab Pte Ltd, Singapore.
GENERAL DECRIPTION
SA -700 contains scale inhibitor and designed to prevent scale deposition in the cooling Water
systems. Components includes organic dispersing agent & scale inhibitor.
COMPOSITION
- 1. Chemical composition…………………….. Hydroxyethylidence-1,1-disphosphonic acid
- 2. Molecular weight …………………………. 206
- 3. Structure formula ………………………….
TYPICAL DATA
SA – 500 is designed to:
- 1. Appearance………... …………………. Lightly yellow, limpid liquid
- 2. Active matter……………………………… 60%
- 3. PH 50 g/l solution ……………………….. Lower than 2
- 4. Density at 20o C…………………………… 1.44 g/ml
- 5. Sequestering power at pH 10.. 512.5 mg CaCO3 per g of product as is
PHYSICAL-CHEMICAL CHARACTERISTIC
- 1. Solubility in water…………………………. Mixable in any proportion
- 2. Solidification point………………………… Lower than – 5o C
